CMSC330

NFA and DFA

Regex to NFA

NFA to DFA

DFA to Regex

NFA and DFA

So far we have only really looked at DFAs

DFA: Deterministic Finite Automata

Easy to check regex acceptance

But machines hard to create

Here is /(a|b)*abb/'s DFA

We can create NFA much easier

NFA: Nondeterministic Finite Automata

Harder to check regex acceptance

Machine easier to make

Here is /(a|b)*abb/'s NFA

Multiple transitions on same symbols

Many ways to accept

Can have epislon (\(\epsilon\)) transitions

First: define a FSM

Alphabet (\(\sum\))
Set of States (\(Q\))
Start State (\(q_0 \in Q\))
Final States (\(F \subseteq Q\))
DFA Transitions (\(\delta: Q \times \sum \mapsto Q\))
NFA Transitions (\(\delta: Q \times (\sum \cup \{\epsilon\}) \mapsto Q\))

Accepting with DFA is easy

Accepting with NFA is hard

Accepting with DFA is easy

Accepting with NFA is hard

Good news: can convert between NFA and DFA

with the help of regex

All DFAs are NFAs

Regex to NFA

NFAs are easy to build: start here

Regex to NFA is dependent on what we need for Regex

Alphabet
Concatenation
Union
Kleene Closure

\(\emptyset\): The language is null

\(\epsilon\): empty string

\(\sigma\): A letter in the alphabet

Concatenation: \(\{xy\vert x \in L_1 \land y \in L_2\}\)

Union: \(\{x\vert x \in L_1 \lor x \in L_2\}\)

Kleene Closure: \(\{x\vert x \in \{\epsilon\} \lor x \in L_1 \lor x \in L_1L_1 \lor \dots\}\)

NFA to DFA

NFAs: hard to check acceptance

DFAs: easy to check acceptance

Convert from NFA to DFA

Basis: combine states to represent possible NFA states

(ie. Make a state that represents "could be in S1 or S2")

Basis: combine states to represent possible NFA states

Subset Algorithm

Requires two Functions:

\(\epsilon\)-closure
Move

Basis: combine states to represent possible NFA states

Subset Algorithm

Requires two Functions:

\(\epsilon\)-closure

Which states can I get to using only \(\epsilon\) transitions
Can always reach self

Move

Which states can I get to using one symbol transition
Could be none

\(\epsilon\)-closure

Reached: S0

\(\epsilon\)-closure

Reached: S0,S1

\(\epsilon\)-closure

Reached: S0,S1,S2

\(\epsilon\)-closure

ReachedL S0,S1,S2,S3

\(\epsilon\)-closure


NFA = (alphabet, states,start,finals,transitions)
e-closure(s)
  x = s
  do
    s= x
    x = union(s,{dest|src \in sand (src,e,dest) in transitions})
  while s!= x
  return x

Move

Reached: S1

Move

Reached S1,S4

Move

Reached S1,S4,S5

Move

Reached S1,S4,S5

Just go through transition list

Putting it all together


NFA = (a, states, start,finals,transitions)
DFA = (a, states, start,finals,transitions)
visited = []
let DFA.start = e-closure(start), add to DFA.states
while visited != DFA.states
  add an unvisited state, s, to visited
  for each char in a
    E = move(s)
    e = e-closure(E)
    if e not in DFA.states
      add e to DFA.states
    add (s,char,e) DFA.transitions
DFA.final = {r| s \in r and s \in NFA.final}
