Gates | ![]() |
|||||||||||||
Gates: NOT Mr. Bill! | ||||||||||||||
Basic building blocks for circuits | ||||||||||||||
Implement boolean functions in hardware | ||||||||||||||
Computer engineering: how to build it physically | ||||||||||||||
Computer organization: how to design it logically | ||||||||||||||
Combinational circuits | ||||||||||||||
Output depends only on input | ||||||||||||||
Sequential circuits | ||||||||||||||
Output depends on input AND current state | ||||||||||||||
