The GUI RIPPER analyzes the GUI of an application. It traverses the application's GUI hierarchically, and produces a tree similar to the integration tree. The structure is called the GUI TREE.  In this structure, each node of the tree represents one GUI component.

GUITAR implements two types of GUI Rippers

Windows GUI RIPPER

Figure 1. The GUI TREE for produced for WordPad

The Windows GUI Ripper is used for analyzing the GUI of Windows applications. Figure 1. shows the Windows GUI Ripper after it has analyzed WordPad.
